| D | 32 | mm | |
| C | 45 | mm | |
| C2 | 1.60 | ||
| e (Minimum size in relation to Ø d.) | 10 |
| A | 60 | mm | |
| C1 | 31.20 | H13 | |
| D1 | 30.50 | mm |
| amax | 100 | m/s² | |
| m | 0.08 | kg | |
| Breakaway force (One wiper seal: Multiply by a factor of 0.5.) | 16 | N | |
| Rows of balls | 4 | ||
| Shaft radial clearance h6/bore K7 | + 31 - 2 |
||
| Permissible ambient temperature (min ... max) (Only unsealed Linear Bushings with steel ball retainers may be used at higher temperatures. Make allowance for reductions in load capacity. ) | -10 °C ... +80 °C |
| vmax | 2.50 | m/s | |
| FR (One wiper seal: Multiply by a factor of 0.5.,Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) | 6 | N | |
| m (Friction coefficients of unsealed Linear Bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load. ) | 0,001 ... 0,004 | ||
| Shaft radial clearance h6/bore H7 | + 49 + 16 |
||
| Operating conditions | Operating conditions |
