REXROTH R044506331 miniature guide rail resist nrii

Name: R044506331 REXROTH
Brand: REXROTH
SKU: 432201-en-gbp
Price: 105.7 GBP
Availability: InStock

MSA-020-SNS-H-MA-AB

£105.70 /m

available with 3 to 4 week lead time shipping to United States

Specifications

For runner blocks R0442 and R0444.
Guide rails are made of rust and acid resistant material similar to ISO 683-17 / EN 10088.
Cover strip optional (made of corrosion-resistant steel)

Series (R0445)	SNS standard, miniature ball guide rail without / with cover strip R0445
Size (0)	20 size
Cover strip (6)	with cover strip

Accuracy class (3)	H Hight Accuracy Level
Sections (31)	One-piece

A₂	20	mm
Dimension H₂ without cover strip	15	mm
ØS₅	6	mm
T_{1 min}	6.50	mm
L_max (For rail lengths longer than L_max factory-coordinated mating sections are joined end-to-end. ,For special cases, one-piece rail lengths of up to 2000 mm are also possible (please consult us). )	1,000	mm
