| Material tubing clamp component | High-alloy stainless steel | ||
| Material release ring | POM | ||
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 2 | For tubing outside diameter of 8 mm | ||
| Product weight | 16 g | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com | ||
| Temperature-dependent operating pressure | -0,95 bar ... 14 bar | ||
| Design | Push-pull principle | ||
| Mounting position | optional | ||
| Size | Standard |
| Material tubing seal | NBR | ||
| Material housing | PBT | ||
| Colour of release ring | Blue | ||
| Pneumatic connection, port 1 | Female thread G1/8 | ||
| Ambient temperature | -10 °C ... 80 °C | ||
| Note on operating and pilot medium | Lubricated operation possible | ||
| Maritime classification | See certificate | ||
| Operating pressure complete temperature range | -0,95 bar ... 6 bar | ||
| Size of pack | 10 | ||
| Nominal size | 6 mm |
