| Part # | PLANT MAS XTRM 250 1.1/2"xRL61 | ||
| Continuous Operating Temperature Range | -40°F to +212°F | ||
| Min. Burst Pressure (psi) | 1,000 | ||
| Hose Inside Diameter (mm) | 38.10 | ||
| Hose Outside Diameter (mm) | 50.80 | ||
| Inside Diameter (mm) | 38 | ||
| Max. Working Pressure | 250 | ||
| Length (m) | 60.96 | ||
| Outside Diameter (mm) | 50.80 | ||
| UPC | 072053212600 | ||
| Use | Industrial Hose | ||
| Cover | MODIFIED NITRILE | ||
| Tube | Type C (Nitrile). Black. | ||
| Construction: Design Factor | 3 | ||
| Construction: Tube | NBR | ||
| Standards: Cover | ARPM (Class B) Medium oil-resistance. | ||
| Couplings Note | Select Ind Hose Coupling Reference Sheet link below for additional information. |
| Product # | 3205-00055 | ||
| Minimum Bend Radius (mm) | 300 | ||
| Hose Inside Diameter (in) | 1.50 | ||
| Hose Outside Diameter (in) | 2 | ||
| Inside Diameter (in) | 1.1/2 | ||
| Temperature Range | -40/100 | ||
| Max. Working Pressure (Bar) | 17 | ||
| Outside Diameter (in) | 2 | ||
| Markets/Applications | Water & Air / Multi-purpose | ||
| Coupling Recommendation | Power Crimp® Couplings Section I, (See Crimp Data Manual 428-7365 or E-Crimp), GLX® Couplings (G44) Section L | ||
| Color | Red | ||
| Reinforcement | Synthetic, high tensile textile cord. | ||
| Construction: Cover | Type C2 (Modified Nitrile). Red. | ||
| Construction: Reinforcement | YS | ||
| Standards | Non-conductive (>1 Megohm/in.). Storage and use may adversely affect electrical resistance. | ||
| Standards: Tube | ARPM (Class A) High oil-resistance. | ||
| Weight (lbs.) | 0.85 |
