| Suction cup shape | Oval, flat | ||
| Mounting position | optional | ||
| Suction cup volume | 2 cm³ | ||
| Nominal size | 3 mm | ||
| Height compensator for suction cup | 3 mm | ||
| Note on materials | RoHS-compliant | ||
| Shore hardness | 60 +/- 5 | ||
| Vacuum connection | Female thread G1/4 | ||
| Product weight | 29 g | ||
| Holding force at nominal operating pressure | 36 N | ||
| LABS (PWIS) conformity | VDMA24364-A1-L | ||
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | ||
| Operating pressure | -13,775 psi ... 0 psi |
| Symbol | 00991485 | ||
| Position of connection | Top | ||
| Suction cup size | 16x55 mm | ||
| Min. workpiece radius | 10 mm | ||
| Material suction cup | NBR | ||
| Material screw-in stud | Wrought aluminium alloy | ||
| Colour | Black | ||
| Type of mounting | Via vacuum port | ||
| Vertical lateral force at nominal operatin pressure | 40 N | ||
| Ambient temperature | -20 °C ... 80 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Nominal operating pressure | -0,6 bar |
