| Permissible axial displacement | s | max.1.3 | |
| Chamfer dimension of loose flange ring | F | 44 | mm |
| Width | B | 17 | mm |
| Bore diameter | d | 35 | mm |
| chamfer dimension | rmin | min.0.6 | |
| Shoulder diameter of outer ring | D1 | ≈60.33 | |
| Outside diameter | d2 | 72 | mm |
| Manufacturer | Part Number |
|---|---|
| FAG | NU207-E-M1 (FAG) |
