| Bore diameter | d | 120 | mm |
| Width | B | 28 | mm |
| Chamfer dimension of loose flange ring | F | 135 | mm |
| Permissible axial displacement | s | max.3.8 |
| Outside diameter | d2 | 180 | mm |
| Shoulder diameter of outer ring | D1 | ≈159.7 | |
| chamfer dimension | rmin | min.1.1 |
| Manufacturer | Part Number |
|---|---|
| FAG | NU1024-MPAX |
| FAG | NU1024-M1A (FAG) |
