| Size | Standard | ||
| Tubing insertion depth | 21,5 mm | ||
| Size of pack | 1 | ||
| Symbol | 00997424 | ||
| Certificate issuing authority | NSF C0556009 | ||
| Note on operating and pilot medium | Lubricated operation possible | ||
| Suitable for use with food | See declaration of conformity NSF/ANSI 169 | ||
| Note on ambient temperature | With PUN-H: -20°C - 60°C | ||
| Pneumatic connection, port 1 | For tubing outer diameter of 14 mm | ||
| Note on materials | RoHS-compliant | ||
| Guard ring material | High-alloy stainless steel | ||
| Material tubing seal | FPM | ||
| Thrust ring material | PPSU |
| Nominal size | 14 mm | ||
| Mounting position | optional | ||
| Design | Push-pull principle | ||
| Operating pressure complete temperature range | -0,95 bar ... 12 bar | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Corrosion resistance class CRC | 4 - Very high corrosion stress | ||
| Ambient temperature | -5 °C ... 150 °C | ||
| Product weight | 60,6 g | ||
| Pneumatic connection, port 2 | For tubing outside diameter of 14 mm | ||
| Material housing | High-alloy stainless steel | ||
| Material release ring | High-alloy stainless steel | ||
| Material tubing clamp component | High-alloy stainless steel |
