| Thrust ring material | PPSU | ||
| Material tubing seal | FPM | ||
| Guard ring material | High-alloy stainless steel | ||
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | For tubing outer diameter of 12 mm | ||
| Ambient temperature | -20 °C ... 150 °C | ||
| Corrosion resistance class CRC | 4 - Very high corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Operating pressure complete temperature range | -0,95 bar ... 16 bar | ||
| Design | Push-pull principle | ||
| Mounting position | optional | ||
| Tubing insertion depth | 19,6 mm ... 22,4 mm | ||
| Size | Standard |
| Material tubing clamp component | High-alloy stainless steel | ||
| Material release ring | High-alloy stainless steel | ||
| Material housing | High-alloy stainless steel | ||
| Pneumatic connection, port 2 | For tubing outside diameter of 10 mm | ||
| Product weight | 39,6 g | ||
| Suitable for use with food | See declaration of conformity NSF/ANSI 169 | ||
| Note on operating and pilot medium | Lubricated operation possible | ||
| Certificate issuing authority | NSF C0556009 | ||
| Symbol | 00997424 | ||
| Size of pack | 1 | ||
| Note on the tubing insertion depth | Ø10 depth 19.6 mm Ø12 depth 22.4 mm | ||
| Nominal size | 9 mm |
