| Permissible axial displacement | s | max.2.3 | |
| Chamfer dimension of loose flange ring | F | 34 | mm |
| Shoulder diameter of inner ring | d2 | ≈38.1 | |
| Outside diameter | d2 | 62 | mm |
| chamfer dimension | rmin | min.1.1 | |
| Shoulder diameter of outer ring | D1 | ≈50.65 | |
| Width | B | 24 | mm |
| Bore diameter | d | 25 | mm |
| Manufacturer | Part Number |
|---|---|
| FAG | NJ2305-E-M1A-C3 (FAG) |
