| Material insulating sheath | PP | ||
| Material union nut | Nickel-plated die-cast zinc | ||
| Material housing | TPE-U(PUR) | ||
| Material cable sheath | TPE-U(PUR) | ||
| Pollution degree | 3 | ||
| Ambient temperature with moving cable | -5 °C ... 80 °C | ||
| Note on degree of protection | In assembled state | ||
| Test conditions cable | Test conditions on request | ||
| Cable length | 0,623 m | ||
| Current rating at 40°C | 2 A | ||
| Operating voltage DC load voltage | 0 V ... 30 V | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| Electrical connection 2, connector system | M12x1, A-coded to EN 61076-2-101 | ||
| Electrical connection 2, connection type | 4x plug connectors | ||
| Electrical connection 2, function | Analogue output module (green), digital input module (white), analogue input module (yellow), digital output module (red) Controller side | ||
| Electrical connection 1, type of mounting | Screw-type lock | ||
| Electrical connection 1, number of connections/cores | 8 | ||
| Electrical connection 1, cable outlet | Angled | ||
| Electrical connection 1, design | Round | ||
| Product weight | 157 g |
| Material electrical contact | Brass Nickel-plated | ||
| Housing colour | Black | ||
| Cable sheath colour | grey | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | -25 °C ... 80 °C | ||
| Degree of protection | IP65 IP67 | ||
| Cable characteristic | Standard | ||
| Immunity to surge | 0,06 kV | ||
| Nominal DC operating voltage, load voltage | 24 V | ||
| Nominal operating voltage DC | 24 V | ||
| electrical connection 2, type of mounting | Screw-type lock | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Round | ||
| Electrical connection 1, connection pattern | 00992265 | ||
| Electrical connection 1, used connections/cores | 8 | ||
| Electrical connection 1, connector system | M12x1, A-coded to EN 61076-2-101 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Type of mounting | With through-hole |
