| Material insulating sheath | PVC | ||
| Material housing | PVC | ||
| Material cable sheath | PVC | ||
| Pollution degree | 3 | ||
| LABS (PWIS) conformity | VDMA24364 zone III | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Note on degree of protection | In assembled state | ||
| Conductor nominal cross section | AWG24 AWG28 | ||
| Cable structure | 4 x (2 x 0.081 mm²) + 1 x (2 x 0.205 mm²) | ||
| Bending radius, fixed cable | ≥ 68 mm | ||
| Cable characteristic | Standard | ||
| Shielding | yes | ||
| Current rating at 40°C | 1,6 A | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| Electrical connection 2, used connections/cores | 6 | ||
| Electrical connection 2, connector system | Connection pattern RE | ||
| Electrical connection 2, connection type | Plugs | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, used connections/cores | 6 | ||
| Electrical connection 1, connector system | Connection pattern RE | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Additional functions | for battery |
| Housing colour | grey | ||
| Cable sheath colour | Black | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| CE marking (see declaration of conformity) | To UK RoHS instructions | ||
| Ambient temperature | -40 °C ... 80 °C | ||
| Degree of protection | IP20 | ||
| Nominal cross section conductor | 0,081 mm² | ||
| Cable diameter | 6,8 mm | ||
| Test conditions cable | Test conditions on request | ||
| Cable length | 0,5 m | ||
| Immunity to surge | 2 kV | ||
| Operational voltage range AC | 0 V ... 30 V | ||
| Electrical connection 2, connection pattern | 00995792 | ||
| Electrical connection 2, number of connections/cores | 6 | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Angular | ||
| Electrical connection 1, connection pattern | 00995793 | ||
| Electrical connection 1, number of connections/cores | 6 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Angular | ||
| Product weight | 66 g |
