| Material insulating sheath | PP | ||
| Material seals | NBR | ||
| Housing colour | Black | ||
| Cable sheath colour | Silver-grey | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| Certificate issuing authority | UL E474609 | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Ambient temperature | -25 °C ... 90 °C | ||
| Degree of protection | IP65 IP67 | ||
| Cable structure | 5 x 0.34 mm² | ||
| Cable diameter | 5,1 mm | ||
| Bending radius, fixed cable | ≥ 26 mm | ||
| Cable characteristic | Suitable for energy chains | ||
| Shielding | no | ||
| Current rating at 40°C | 2 A | ||
| Operational voltage range DC | 0 V ... 60 V | ||
| Electrical connection 2, connection pattern | 00991172 | ||
| Electrical connection 2, used connections/cores | 3 | ||
| Electrical connection 2, connector system | M12x1, A-coded to EN 61076-2-101 | ||
| Electrical connection 2, connection type | Plugs | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, type of mounting | Screw-type lock | ||
| Electrical connection 1, number of connections/cores | 8 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Round | ||
| Product weight | 30 g | ||
| Approval | c UL us listed (OL) | ||
| Based on standard | EN 61076-2-101 |
| Material electrical contact | Brass | ||
| Material screw-type lock | Die-cast zinc, nickel-plated | ||
| Material housing | TPE-U(PUR) | ||
| Material cable sheath | TPE-U(PUR) | ||
| Pollution degree | 3 | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| CE marking (see declaration of conformity) | To UK RoHS instructions | ||
| Ambient temperature with moving cable | -25 °C ... 90 °C | ||
| Note on degree of protection | In assembled state | ||
| Nominal cross section conductor | 0,34 mm² | ||
| Cable diameter tolerance | ± 0.2 mm | ||
| Bending radius, moving cable | ≥ 26 mm | ||
| Test conditions cable | Test conditions on request | ||
| Cable length | 0,3 m | ||
| Immunity to surge | 0,8 kV | ||
| Operational voltage range AC | 0 V ... 48 V | ||
| Electrical connection 3, used connections/cores | 3 | ||
| electrical connection 2, type of mounting | Screw-type lock | ||
| Electrical connection 2, number of connections/cores | 5 | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Round | ||
| Electrical connection 1, connection pattern | 00992265 | ||
| Electrical connection 1, used connections/cores | 3 | ||
| Electrical connection 1, connector system | M12x1, A-coded to EN 61076-2-101 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Cable designation | Without inscription label holder | ||
| Protocol | IO-Link® |
