| Material housing | PC-reinforced | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | -20 °C ... 70 °C | ||
| Connection cross section | 0,08 mm² ... 0,5 mm² | ||
| Baud rate | 12 Mbit/s | ||
| Electrical connection 1 | Sub-D plug, 9-pin | ||
| Product weight | 57,48 g |
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Relative air humidity | 75% at 25ºC | ||
| Degree of protection | IP20 | ||
| Permissible cable diameter | 8 mm | ||
| Electrical connection 2 | IDC terminal | ||
| Field bus interface | Sub-D, 9-pin, socket | ||
| Type of mounting | 4-40 UNC-2B |
