| Material electrical contact | Brass White bronze coated | ||
| Material housing | PA | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | -25 °C ... 85 °C | ||
| Connection cross section | 0,14 mm² ... 0,5 mm² | ||
| Cable fitting | Pg7 | ||
| Current rating at 40°C | 4 A | ||
| Electrical connection 2, connector system | Screw terminal | ||
| Electrical connection 1, connection pattern | 00995386 | ||
| Electrical connection 1, number of connections/cores | 4 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Round | ||
| Product weight | 18 g | ||
| Frequency of connection | 50 | ||
| Based on standard | EN 61076-2-101 EN 61984 |
| Material union nut | PA | ||
| Pollution degree | 3 | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| Degree of protection | IP65 IP67 | ||
| Permissible cable diameter | 2,5 mm ... 2,9 mm | ||
| Immunity to surge | 2,5 kV | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| Electrical connection 2, connection type | Cable | ||
| Electrical connection 1, type of mounting | Screw-type lock with 18 mm hexagon and longitudinal knurl | ||
| Electrical connection 1, connector system | M12x1, A-coded to EN 61076-2-101 | ||
| Electrical connection 1, connection type | Plugs | ||
| Electrical connection 1, function | Field device side | ||
| Mounting position | optional | ||
| Explosion protection | The information in the certificate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
