| Material electrical contact | Bronze Bronze | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| Degree of protection | IP65 IP67 | ||
| Permissible cable diameter | 4 mm ... 8 mm | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| Electrical connection | 4-pin Spring-loaded terminal M12x1 Straight plug | ||
| Mounting position | optional | ||
| Based on standard | EN 61076-2-101 |
| Material housing | Die-cast zinc Nickel-plated | ||
| Pollution degree | 3 | ||
| Ambient temperature | -40 °C ... 85 °C | ||
| Connection cross section | 0,14 mm² ... 0,5 mm² | ||
| Current rating at 40°C | 4 A | ||
| Plug encoding | A | ||
| Product weight | 38 g | ||
| Explosion protection | The information in the certificate must be observed! Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
