| Material electrical contact | Brass Bronze | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | -25 °C ... 85 °C | ||
| Connection cross section | 0,14 mm² ... 0,75 mm² | ||
| Transmission characteristics | DIN EN 50173/CAT 5 | ||
| Current rating at 40°C | 4 A | ||
| Operational voltage range DC | 0 V ... 125 V | ||
| Plug encoding | B | ||
| Product weight | 48,7 g |
| Material housing | Die-cast zinc Nickel-plated | ||
| Pollution degree | 3 | ||
| CE mark (see declaration of conformity) | To EU Low Voltage Directive | ||
| Degree of protection | IP67 | ||
| Permissible cable diameter | 6 mm ... 8 mm | ||
| Immunity to surge | 1,5 kV | ||
| Operational voltage range AC | 0 V ... 125 V | ||
| Electrical connection 2 | Screw terminal, can be screened | ||
| Electrical connection 1 | Straight socket, M12x1, 5-pin, B-coded, screenable | ||
| Based on standard | EN 61076-2-101 EN 61984 |
