| Material insulating sheath | TPE-E | ||
| Material housing | PA | ||
| Material cable sheath | TPE-U(PUR) | ||
| Pollution degree | 3 | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Ambient temperature | -25 °C ... 80 °C | ||
| Degree of protection | IP20 | ||
| Nominal cross section conductor | 1,5 mm² | ||
| Cable diameter | 6,7 mm | ||
| Bending radius, fixed cable | ≥ 21 mm | ||
| Cable characteristic | Suitable for energy chains | ||
| Immunity to surge | 1,5 kV | ||
| Operational voltage range AC | 0 V ... 30 V | ||
| Electrical connection 2, used connections/cores | 2 | ||
| Electrical connection 2, connector system | Open end | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, used connections/cores | 2 | ||
| Electrical connection 1, connector system | Connection pattern L4 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side |
| Housing colour | Black | ||
| Cable sheath colour | grey | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| CE marking (see declaration of conformity) | To UK RoHS instructions | ||
| Ambient temperature with moving cable | -25 °C ... 80 °C | ||
| Note on degree of protection | IP65 for mounting in terminal box | ||
| Wire ends | Cut off bluntly | ||
| Cable structure | 2 x 1.5 mm² | ||
| Bending radius, moving cable | ≥ 34 mm | ||
| Test conditions cable | Test conditions on request | ||
| Cable length | 10 m | ||
| Current rating at 40°C | 10 A | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| Electrical connection 2, number of connections/cores | 2 | ||
| Electrical connection 2, connection type | Cable | ||
| Electrical connection 1, connection pattern | 00995784 | ||
| Electrical connection 1, number of connections/cores | 2 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Angular | ||
| Cable designation | Without inscription label holder |
