FESTO 571468 water separator

Name: 571468 FESTO
Brand: FESTO
SKU: 665355-en-gbp
Price: 495.11 GBP
Availability: InStock

MS9-LWS-G-U-V

£495.11

2 pcs. with 1 to 3 days delivery to United States

Specifications

Series (MS)	MS series
Size (9)	Grid dimension 90 mm
Function (LWS)	Water separator
Pneumatic connection (G)	Module without connecting thread, without sub-base
Bowl type (U)	Aluminium

Condensate drain (V)	Automatic
Type of mounting	Without mounting bracket
EU certification	None
UL certification	None
Flow direction	Flow direction from left to right

Material separating plate		POM
Material cup seal		NBR
Material module connector		Die-cast aluminium
Material mounting bracket		Die-cast aluminium
Note on materials		RoHS-compliant
Material covering		PA-reinforced
Product weight		2.000 g
Media temperature		-10 °C ... 60 °C
Storage temperature		5 °C ... 60 °C
Corrosion resistance class CRC		2 - Moderate corrosion stress
Operating medium		Compressed air to ISO 8573-1:2010 [-:7:4]
Operating pressure		2 bar ... 12 bar
Degree of condensate separation		99 %
Max. condensate volume		220 ml
Condensate drain		Fully automatic
Series		MS

Material screen		PA
Material bowl		Wrought aluminium alloy
Material housing		Die-cast aluminium
Material sub-base		Die-cast aluminium
Material spin disc		POM
Type of mounting		In-line installation With accessories Either:
Ambient temperature		-10 °C ... 60 °C
Air purity class at output		Compressed air to ISO 8573-1:2010 [-:7:4]
LABS (PWIS) conformity		VDMA24364-B1/B2-L
Vibration resistance		Transport application test with severity level 1 to FN 942017-4 and EN 60068-2-6
Standard nominal flow rate		15.000 l/min
Symbol		00992244
Bowl guard		Integrated as metal bowl
Design		Centrifugal separator
Mounting position		Vertical +/-5°
Size		9
