| Type of mounting | With H-rail | ||
| Connection cross section | 2,5 mm² | ||
| Mounting position | optional | ||
| Degree of protection | IP20 | ||
| CE mark (see declaration of conformity) | To EU EMC Directive | ||
| Potentiometer external setpoint input | 2,5 kOhm ... 10 kOhm | ||
| Supply voltage setpoint adjustment | 10 V ... 10,6 V | ||
| Residual ripple | 10 % | ||
| Power consumption at 24VDC | 1,5 W | ||
| Input resistance setpoint input | 3 kOhm | ||
| Operational voltage range DC | 20 V ... 30 V | ||
| Display enabled setpoint | Yellow LED |
| Electrical connection | Screw terminal | ||
| Product weight | 80 g | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Approval | C-Tick | ||
| Supply current setpoint adjustment | 6 mA ... 6,36 mA | ||
| Voltage external setpoint input | 0 V ... 10 V | ||
| Max. output current | 27 mA | ||
| Adjustable output voltage | 0 V ... 10 V | ||
| Input resistance external setpoint input | Typ. 100 kOhm | ||
| Ready status indication | Green LED |
