| Material winding | Copper | ||
| Note on materials | Contains paint-wetting impairment substances | ||
| Electrical connection | To DIN EN 175301-803 | ||
| Max. tightening torque for fitting | 2 Nm | ||
| Note on degree of protection | IP00 without connector socket | ||
| Permissible voltage fluctuations | +/- 10 % | ||
| Characteristic coil data | 24 V DC: 7.9 W | ||
| Duty cycle | 100% | ||
| Switching position indicator | no |
| Material solenoid coil | Duroplast Copper Steel | ||
| Type of mounting | Via lock nut | ||
| Product weight | 150 g | ||
| Ambient temperature | -20 °C ... 50 °C | ||
| Degree of protection | IP65 | ||
| Permissible frequency fluctuations | +/- 10% | ||
| Power factor (cos phi) | 0,7 | ||
| Min. pick-up time | 12 ms | ||
| Mounting position | optional |
