| Material housing | Aluminium Die-cast zinc | ||
| Pneumatic connection, port 2 | For tubing outside diameter of 4 mm | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure complete temperature range | -0,95 bar ... 10 bar | ||
| Nominal size | 2 mm |
| Note on materials | RoHS-compliant | ||
| Pneumatic connection, port 1 | Male thread G1/8 | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Type of seal on screw-in stud | Sealing ring |
