| air flow direction | uni-directional | ||
| bowl type | metal with liquid level indicator | ||
| drain type | closed bowl | ||
| flow flow dm3sec | 21 dm3/sec | ||
| flow imperial flow scfm | 45 scfm | ||
| maximum inlet pressure imperial pressure psi | 246 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 65 °c | ||
| range | l82m | ||
| start point flow dm3sec | 1.2 dm3/sec |
| bowl | diecast aluminium | ||
| data performance shelf life | 3 years | ||
| excelon plus series | 82 series | ||
| flow flow dm3secbar | 21 dm3/(s.bar) dm3/sec | ||
| fog type | micro fog | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 149 °f | ||
| Port size | g3/8 | ||
| Series | excelon plus | ||
| start point imperial flow scfm | 2.5 scfm |
