NORGREN L82M-2GP-EPN

Name: L82M-2GP-EPN NORGREN
Brand: NORGREN
SKU: 790483-en-gbp
Price: 56.89 GBP
Availability: InStock

£56.89 ~~£61.47~~ -7%

1 pcs. with 1 to 3 days delivery to United States

Specifications

max. pressure	10 bar

Width	52mm

air flow direction		uni-directional
bowl type		polymer with guard
drain type		closed bowl
excelon plus series		82 series
flow flow dm3secbar		22 dm3/(s.bar) dm3/sec
fog type		micro fog
maximum inlet pressure pressure bar		10 bar
mil spec		available on request
operating temperature temperature celsius min to max range		-10 ... 60 °c
length length millimetre		187 mm
Port size		g1/4
Series		excelon plus
start point imperial flow scfm		2.5 scfm

bowl		polycarbonate
data performance shelf life		10 years
eu country of origin		mexico
flow flow dm3sec		22 dm3/sec
flow imperial flow scfm		46 scfm
maximum inlet pressure imperial pressure psi		145 psig
Medium		compressed air
operating temperature f temperature fahrenheit min to max range		14 ... 140 °f
height length millimetre		47 mm
width length millimetre		52 mm
range		l82m
start point flow dm3sec		1.2 dm3/sec
