| Material insulating sheath | TPE-U(PUR) | ||
| Material screw-type lock | Nickel-plated brass | ||
| Material housing | PA PBT TPE-U(PUR) | ||
| Material cable sheath | TPE-U(PUR) | ||
| Pollution degree | 1 | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Ambient temperature | -20 °C ... 80 °C | ||
| Degree of protection | IP65 IP67 | ||
| Cable structure | 2 x 0.25 mm² + 2 x 0.34 mm² + 0.49 mm² Shielded | ||
| Bending radius, moving cable | ≥ 75 mm | ||
| Cable characteristic | Suitable for energy chains | ||
| Immunity to surge | 1,5 kV | ||
| Current rating at 40°C | 1,6 A | ||
| Electrical connection 2, connection pattern | 00992012 | ||
| Electrical connection 2, used connections/cores | 5 | ||
| Electrical connection 2, connector system | M9x0.5 | ||
| Electrical connection 2, connection type | Plugs | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, type of mounting | Screw-type lock | ||
| Electrical connection 1, number of connections/cores | 5 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Round | ||
| Product weight | 113,8 g | ||
| Cable designation | With accessories |
| Material electrical contact | Gold-plated bronze Gold-plated brass | ||
| Housing colour | Black | ||
| Cable sheath colour | Light grey | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Note on materials | RoHS-compliant | ||
| CE marking (see declaration of conformity) | To UK RoHS instructions | ||
| Ambient temperature with moving cable | -5 °C ... 80 °C | ||
| Note on degree of protection | In assembled state | ||
| Nominal cross section conductor | 0,49 mm² | ||
| Cable diameter | 5,5 mm | ||
| Test conditions cable | Test conditions on request | ||
| Cable length | 2 m | ||
| Note on permissible current load at 40°C | 2.3 A for 0.34 mm² 3.6 A for 0.49 mm² | ||
| Operational voltage range DC | 0 V ... 30 V | ||
| electrical connection 2, type of mounting | Screw-type lock | ||
| Electrical connection 2, number of connections/cores | 5 | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Round | ||
| Electrical connection 1, connection pattern | 00995398 | ||
| Electrical connection 1, used connections/cores | 5 | ||
| Electrical connection 1, connector system | M9x0.5 | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Frequency of connection | 500 | ||
| Additional functions | Contact 3 of socket 1 mm leading |
