| Material electrical contact | Bronze | ||
| Material cable sheath | TPE-U(PUR) | ||
| Note on materials | RoHS-compliant | ||
| CE marking (see declaration of conformity) | To UK RoHS instructions | ||
| Ambient temperature | -10 °C ... 50 °C | ||
| Cable structure | 2 x 0.25 mm² | ||
| Cable characteristic | Standard | ||
| Protective conductor connection | Not available | ||
| Nominal operating voltage DC | 24 V | ||
| Product weight | 90 g | ||
| Type of mounting | On solenoid valve via self-tapping screw | ||
| Maritime classification | See certificate |
| Material housing | PA | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive | ||
| Degree of protection | IP65 | ||
| Cable diameter | 3,4 mm | ||
| Cable length | 5 m | ||
| Current rating at 40°C | 1 A | ||
| Electrical connection | 2-pin/2-wire Angled socket/cable Square design/open end | ||
| Mounting position | optional | ||
| Switching position indicator | LED |
