| Material seals | NBR | ||
| Product weight | 41 g | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Symbol | 00997328 | ||
| Type of piloting | Direct | ||
| Mounting position | optional | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Nominal size | 4,7 mm | ||
| Type of mounting | Direct mounting via through-hole In-line installation Either: | ||
| Pneumatic connection, port 2 | QS-10 | ||
| Valve function | 2/2 double solenoid |
| Note on materials | RoHS-compliant | ||
| Media temperature | 0 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Flow direction | Reversible | ||
| Design | Piston gate valve | ||
| Sealing principle | Soft | ||
| Material housing | PBT-reinforced | ||
| Operating pressure | -0,95 bar ... 10 bar | ||
| Standard nominal flow rate | 752,4 l/min | ||
| Type of actuation | Manual | ||
| Pneumatic connection, port 1 | QS-10 |
