| Shoulder diameter inner ring | d1 | 114.40 | mm |
| Minimum chamfer dimension | rmin | 3 | mm |
| Shoulder diameter outer ring | D1 | 151.58 | mm |
| Maximum fillet radius | ra max | 2.50 | mm |
| Minimum diameter shaft shoulder | da min | 99 | mm |
| Maximum diameter of housing shoulder | Da max | 166 | mm |
| Limiting speed | nG | 7,900 | |
| Basic static load rating, radial | C0r | 126,000 | |
| Width | B | 41 | mm |
| Bore diameter | d | 85 | mm |
| Fatigue load limit, radial | Cur | 4,350 | |
| Basic dynamic load rating, radial | Cr | 167,000 | |
| Outside diameter | D | 180 | mm |
