| Note on materials | RoHS-compliant | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Min. diff. pressure, opening | 0,1 bar | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Material housing | Anodised aluminium | ||
| Operating pressure | -1 bar ... 10 bar | ||
| Type of mounting | In-line installation | ||
| Pneumatic connection, port 1 | QS-6 |
| Product weight | 10 g | ||
| Min. diff. pressure, closing | 0,2 bar | ||
| Symbol | 00991455 | ||
| Housing colour | Black | ||
| Ambient temperature | 0 °C ... 60 °C | ||
| Standard nominal flow rate | 282 l/min | ||
| Pneumatic connection, port 2 | QS-6 | ||
| Valve function | Non-return function |
