| Angle between Set Screws | 90 º | ||
| Set Screw Size | M10 x 1.5 | ||
| Dimension J | 10 | ||
| Dimension S1 | 39.67 | mm | |
| Radius r | 0.60 | mm | |
| Inner Ring Width B | 65.07 | mm |
| Number of Set Screws | 2 | ||
| Dimension M | 5.13 | mm | |
| Dimension F | 76.48 | mm | |
| Center of Bearing from End S | 25.40 | mm | |
| Outside Ring Width C | 27 | mm | |
| Outside Diameter D | 110 | mm |
| Weight | 0.20 | Kg | |
| Sub Series | GY…KRRB | ||
| O.D. Type | Spherical OD | ||
| Material | Bearing Steel | ||
| Bore Type | Cylindrical bore |
| Seal Type | Shroud Seal | ||
| Series | Industrial | ||
| Lubrication Type | Relubricatable | ||
| Bearing Type | Ball Bearing | ||
| Shaft Size d | 2 1/4 in |
