| Material swivel fitting | Die-cast zinc Chromated | ||
| Material release ring | POM | ||
| Note on materials | RoHS-compliant | ||
| Product weight | 13 g | ||
| Nominal torque | 0,8 Nm | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Standard flow rate in non-return direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 150 l/min ... 170 l/min | ||
| Operating pressure complete temperature range | 0,2 bar ... 10 bar | ||
| Mounting position | optional | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Standard nominal flow rate in flow control direction | 100 l/min | ||
| Adjustment component | Slotted head screw | ||
| Pneumatic connection, port 1 | QS-3 |
| Material adjusting screw | Brass | ||
| Material seals | NBR | ||
| Material screw-in stud | Brass | ||
| Tolerance for nominal tightening torque | ± 10% | ||
| Media temperature | -10 °C ... 60 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) | 145 l/min | ||
| Symbol | 00991452 | ||
| Maritime classification | See certificate | ||
| Standard nominal flow rate in blocked direction | 60 l/min ... 100 l/min | ||
| Type of mounting | Screw-in | ||
| Pneumatic connection, port 2 | M5 | ||
| Valve function | Exhaust air one-way flow control function |
