| Material adjusting screw | Brass | ||
| Media temperature | -10 °C ... 60 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Mounting position | optional | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Standard nominal flow rate in blocked direction | 45 l/min | ||
| Type of mounting | With through-hole | ||
| Pneumatic connection, port 2 | PK-3 | ||
| Valve function | One-way flow control function |
| Product weight | 95 g | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Symbol | 00991453 | ||
| Material housing | Wrought aluminium alloy | ||
| Operating pressure | 0,5 bar ... 8 bar | ||
| Standard nominal flow rate in flow control direction | 45 l/min | ||
| Adjustment component | Knurled screw | ||
| Pneumatic connection, port 1 | PK-3 |
