| Dimension B2 | 17.50 | mm | |
| Dimension M | 3.61 | mm | |
| Angle between Set Screws | 90 º | ||
| Set Screw Size | 5/16-18 | ||
| Radius r | 0.60 | mm | |
| Inner Ring Width B | 36.51 | mm |
| Dimension B1 | 50 | mm | |
| Dimension d1 | 49.20 | mm | |
| Number of Set Screws | 2 | ||
| Center of Bearing from End S | 17.50 | mm | |
| Outside Ring Width C | 20 | mm | |
| Outside Diameter D | 72 | mm |
| Weight | 0.20 | Kg | |
| Sub Series | GN..KRRB | ||
| O.D. Type | Spherical OD | ||
| Material | Bearing Steel | ||
| Bore Type | Cylindrical bore | ||
| Manufacturing Part Number | GN103KRRB + COL |
| Seal Type | Shroud Seal | ||
| Series | Medium-Duty | ||
| Lubrication Type | Relubricatable | ||
| Bearing Type | Ball Bearing | ||
| Shaft Size d | 1 3/16 in |
