| Material housing | ABS | ||
| Product weight | 450 g | ||
| Note on operating and pilot medium | Lubricated operation not possible | ||
| Explosion ambient temperature | +5°C <= Ta <= +40°C | ||
| Explosion ignition protection type for gas | Ex h IIC T4 Gb | ||
| ATEX category gas | II 2G | ||
| Explosion protection certification outside the EU | EPL Dc (GB) EPL Gb (GB) | ||
| CE mark (see declaration of conformity) | To EU Explosion Protection Directive (ATEX) | ||
| Standard nominal flow rate | 60 l/min | ||
| Response pressure acknowledgement | ≥ 1,5 bar | ||
| Design | Sequencer, additive |
| Material seals | NBR | ||
| Ambient temperature | 5 °C ... 40 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:4] | ||
| Explosion ignition protection type for dust | Ex h IIIC T125°C Dc | ||
| ATEX category dust | II 3D | ||
| Explosion protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 22 (ATEX) | ||
| CE marking (see declaration of conformity) | To UK EX instructions | ||
| Min. pulse length acknowledgement | 50 ms | ||
| Operating pressure | 2,5 bar ... 6 bar | ||
| Drop-off pressure acknowledgement | ≤ 0,5 bar | ||
| Nominal size | 2,5 mm |
