| Material electrical contact | Copper alloy Nickel-plated and gold-plated | ||
| Material housing | Die-cast zinc Nickel-plated | ||
| Note on materials | RoHS-compliant | ||
| Ambient temperature | -40 °C ... 70 °C | ||
| Permissible cable diameter | 5 mm ... 8 mm | ||
| Specification Ethernet cable | Type: CAT.5 Individual wire diameter: max. 1.6 mm 0.13 - 0.36 mm², 7-wire 0.13 - 0.36 mm², 1-wire | ||
| Product weight | 60 g | ||
| Height | 72 mm |
| Material seals | NBR | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Storage temperature | -40 °C ... 70 °C | ||
| Degree of protection | IP65 IP67 To IEC 60529 | ||
| Protection against direct and indirect contact | PELV | ||
| Note on fieldbus interface | PROFINET | ||
| Length | 22 mm | ||
| Width | 30 mm |
