FESTO 118661 piston magnet

Name: 118661 FESTO
Brand: FESTO
SKU: 664452-en-gbp
Price: 11.23 GBP
Availability: InStock

ESNU- 10- PA

£11.23 ~~£14.97~~ -24%

available with 3 to 4 week lead time shipping to United States

Specifications

Pneumatic connection	M5
Weight	373g

Impact energy in end positions		0,05 J
Piston diameter		10 mm
Cushioning		Elastic cushioning rings/plates at both ends
Conforms to standard		CETOP RP 52 P ISO 6432
Design		Piston Piston rod Cylinder barrel
Variants		Piston rod at one end
Mode of operation		Single-acting Pushing
Note on operating and pilot medium		Lubricated operation possible (in which case lubricated operation will always be required)
LABS (PWIS) conformity		VDMA24364-B1/B2-L
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke		41,6 N
Additional moving mass per 10 mm stroke		1 g
Additional weight per 10 mm stroke		2,7 g
Pneumatic connection		M5
Material cover		Wrought aluminium alloy Colourless anodised
Material piston rod		High-alloy stainless steel

Stroke		1 mm ... 50 mm
Piston rod thread		M4
Mounting position		optional
Piston-rod end		Male thread
Position detection		Via proximity switch
Operating pressure		1,5 bar ... 10 bar
Operating medium		Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC		2 - Moderate corrosion stress
Ambient temperature		-20 °C ... 80 °C
Moving mass for 0 mm stroke		8,5 g
Basic weight for 0 mm stroke		37,3 g
Type of mounting		With accessories
Note on materials		RoHS-compliant
Material seals		NBR TPE-U(PU)
Material cylinder barrel		High-alloy stainless steel
