| Permissible radial shaft load | 20 N | ||
| Product weight | 268 g | ||
| Mass moment of inertia of rotor | 0,018 kgcm² | ||
| Phase winding resistance | 2,3 Ohm | ||
| Nominal motor current | 1,4 A | ||
| Stepper angle for complete step | 1,8 deg | ||
| Motor holding torque | 0,09 Nm | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions | ||
| Approval | RCM trademark c UL us - Recognized (OL) | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Electrical connector system | Plug | ||
| Rating class as per EN 60034-1 | S1 | ||
| Insulation protection class | B | ||
| Relative air humidity | 0 - 85% | ||
| Ambient temperature | -10 °C ... 50 °C |
| Permissible axial shaft load | 7 N | ||
| Total mass moment of inertia of output | 0,018 kgcm² | ||
| Phase winding inductance | 1,4 mH | ||
| Voltage constant, phase | 6 mVmin | ||
| Stepping angle tolerance | ±5% | ||
| Max. rotational speed | 6.000 rpm | ||
| Nominal operating voltage DC | 48 V | ||
| CE mark (see declaration of conformity) | To EU EMC Directive | ||
| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| Note on materials | RoHS-compliant | ||
| Degree of protection | IP65 | ||
| Temperature class as per EN 60034-1 | B | ||
| Conforms to standard | IEC 60034 | ||
| Storage temperature | -20 °C ... 70 °C |
