| Material yoke plate | Steel | ||
| Material guide component | Tempered steel | ||
| Type of mounting | Via female thread | ||
| Centre of gravity at 0 mm stroke | 46 mm | ||
| Moving mass | 3.975 g | ||
| Max. torque Mz static | 89 Nm | ||
| Max. torque My static | 89 Nm | ||
| Max. torque Mx static | 83 Nm | ||
| Max. force Fz static | 1.600 N | ||
| Max. force Fy static | 1.600 N | ||
| Ambient temperature | -20 °C ... 80 °C | ||
| Design | Guidance | ||
| Mounting position | optional | ||
| Stroke | 400 mm |
| Material housing | Wrought aluminium alloy Anodised | ||
| Note on materials | RoHS-compliant | ||
| Centre of gravity additional of moving mass per 10 mm | 4,3 mm | ||
| Product weight | 6.019 g | ||
| Displacement force | 15 N | ||
| Max. moment Mz | 70 Nm | ||
| Max. moment My | 70 Nm | ||
| Max. moment Mx | 65 Nm | ||
| Max. force Fz | 1.260 N | ||
| Max. force Fy | 1.260 N | ||
| Corrosion resistance class CRC | 0 - No corrosion stress | ||
| Guide | Recirculating ball bearing guide | ||
| Reversing backlash theoretical | 0 µm | ||
| Size | 50 |
