PARKER DSL081CHRTV

Name: DSL081CHRTV PARKER
Brand: PARKER
SKU: 804621-en-gbp
Price: 217.55 GBP
Availability: SoldOut

£217.55 ~~£320.90~~ -32%

Limited stock only available on quotation

Specifications

max. pressure	3600 psi, 250 bar
max. flow	8 gal/min, 30 l/min

Seal	fluorocarbon
Weight	110g

Weight		0.25 lb, 0.11 kg
Input voltage		85% of rated voltage at 72°f (20°c) min
minimum operating temperature		-15 °f, -26 °c
Operating temperature		-15 to +400 °f, -26 to +204 °c
installation torque		23-27 lb-ft, 31-37 nm
filter efficiency rating		iso 4406 18/16/13, sae class 4
for fluid type		mineral-based or synthetic hydraulic fluids
free reverse flow		yes
cavity size		c08-2
maximum operating pressure		3600 psi, 250 bar
Flow direction		side to nose (2-1)
maximum flow rate		8 gal/min, 30 l/min
wire mesh screen included		no
actuation type		electrical, manual
maximum inlet pressure rating		3600 psi, 250 bar

response time		30 ms
coil type		1/2" super coil
maximum operating temperature		+400 °f, +204 °c
coil nut tightening torque		5-7 lb-ft, 7-10 nm
valve material		all parts steel. all operating parts hardened steel
maximum kinematic viscosity		45-2000 ssu (6 to 420 cst)
override functionality		push and twist
function		2-way
leak rate		5 drops/min
operation type		solenoid operated, manually operated
Mounting type		screw in cartridge valve
division		hydraulic cartridge systems division
seal material		fluorocarbon
configuration		normally closed
flow rate		8 gal/min, 30 l/min
