| Material screws | High-alloy stainless steel | ||
| Material threaded pin | High-alloy stainless steel | ||
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant | ||
| Product weight | 1.340 g | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Explosion protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | ||
| Mounting position | optional |
| Material plate | Anodised wrought aluminium alloy | ||
| Material seals | EPDM NBR | ||
| Pneumatic connection | G1/4 | ||
| Ambient temperature | -20 °C ... 80 °C | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Operating pressure | 2 bar ... 8 bar | ||
| Based on standard | VDI/VDE 3845 (NAMUR) |
