| Solenoid Option | Standard solenoid without options | ||
| Spool Position | 2 positions, spring offset in position b, operated in position a | ||
| Bore Diameter (mm) | 26 | ||
| Spool Code | 30 | ||
| Material - Seals | NBR | ||
| Nominal Size | NG25 / CETOP 08 | ||
| Connection Type | Connector as per EN 175301-803 | ||
| Weight | 17.9 kg |
| Maximum Flow Rate (lpm) | 700 | ||
| Series | D81VW | ||
| Pilot Connection (Inlet/Drain) | External/external | ||
| Additional Options | na | ||
| Input Voltage | 24 (DC) | ||
| Operation Type | Pilot | ||
| Mounting Type | Subplate mounting |
