| body | acetal | ||
| grabring | stainless steel | ||
| operating pressure pressure bar min to max range | -0.9 ... 16 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 208 °f | ||
| release sleeve and backing ring | acetal | ||
| Series | pneufit d | ||
| thread | m24 x 1.75 |
| collet | stainless steel | ||
| od tube length millimetre | 10 mm | ||
| operating pressure psi pressure psi min to max range | -14.5 ... 232 psi | ||
| operating temperature temperature celsius min to max range | -20 ... 98 °c | ||
| Seals | epdm | ||
| shape | straight | ||
| tube types | polyethylene |
