| LABS (PWIS) conformity | VDMA24364-B2-L | ||
| Ambient temperature with moving cable | -5 °C ... 60 °C | ||
| Material housing | PP | ||
| Product weight | 70 g | ||
| Material cable sheath | TPE-O | ||
| Cable length | 2,5 m | ||
| Electrical connection 1, number of connections/cores | 3 | ||
| Electrical connection 1, connection type | Cable | ||
| Operational voltage range DC | 12 V ... 30 V | ||
| Short circuit current rating | no | ||
| Max. switching capacity DC | 10 W | ||
| Max. switching frequency | 800 Hz | ||
| Switch-on time | ≤ 0,5 ms | ||
| Switching output | Contacting, bipolar | ||
| Ambient temperature | -20 °C ... 60 °C | ||
| Measured variable | Position | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions | ||
| Approval | RCM trademark | ||
| Design | Round |
| Degree of protection | IP67 | ||
| Switching status indication | Yellow LED | ||
| Housing colour | Black | ||
| Type of mounting | With accessories | ||
| Cable sheath colour | grey | ||
| Connection outlet orientation | In-line | ||
| Electrical connection 1, connector system | Open end | ||
| Reverse polarity protection | no | ||
| Rated operational voltage DC | 24 V | ||
| Inductive protective circuit | Adapted to MZ, MY, ME coils | ||
| Max. output current | 500 mA | ||
| Switch-off time | 0,03 ms | ||
| Switching element function | N/O contact | ||
| Repetition accuracy | 0,2 mm | ||
| Measuring principle | Magnetic reed | ||
| Note on materials | RoHS-compliant | ||
| CE mark (see declaration of conformity) | To EU EMC Directive In accordance with EU RoHS Directive | ||
| Symbol | 00991145 |
