| Material housing | Die-cast zinc | ||
| Note on materials | RoHS-compliant | ||
| Type of mounting | With through-hole | ||
| Ambient temperature | -10 °C ... 60 °C | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| pneumatic working port | M7 |
| Material seals | NBR | ||
| Pneumatic connection, port 2 | M7 | ||
| Product weight | 23 g | ||
| Media temperature | -10 °C ... 60 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure | 2,5 bar ... 10 bar | ||
| Valve function | 5/3 closed |
