| Material housing | Metallised plastic | ||
| Protocol | HIPERFACE | ||
| electrical connection 2, type of mounting | 2x screw 4-40 UNC-2A | ||
| Electrical connection 2, number of connections/cores | 15 | ||
| Electrical connection 2, cable outlet | Straight | ||
| Electrical connection 2, design | Angular | ||
| Electrical connection 1, connection pattern | 00995640 | ||
| Electrical connection 1, number of connections/cores | 15 | ||
| Electrical connection 1, cable outlet | Straight | ||
| Electrical connection 1, design | Angular | ||
| Note on materials | RoHS-compliant | ||
| Note on degree of protection | In assembled state | ||
| Nominal operating voltage AC | 24 V | ||
| Nominal operating voltage DC | 24 V |
| Housing colour | Silver | ||
| Electrical connection 2, connection pattern | 00995641 | ||
| Electrical connection 2, used connections/cores | 8 | ||
| Electrical connection 2, connector system | Sub-D | ||
| Electrical connection 2, connection type | Plugs | ||
| Electrical connection 2, function | Controller side | ||
| Electrical connection 1, used connections/cores | 8 | ||
| Electrical connection 1, connector system | Sub-D | ||
| Electrical connection 1, connection type | Socket | ||
| Electrical connection 1, function | Field device side | ||
| Ambient temperature | -40 °C ... 80 °C | ||
| Degree of protection | IP30 | ||
| Operational voltage range AC | 0 V ... 30 V | ||
| Operational voltage range DC | 0 V ... 30 V |
