SKF C 2217 V/C3

Name: C 2217 V/C3 SKF
Brand: SKF
SKU: 624484-en-gbp
Price: 616.93 GBP
Availability: SoldOut

85mm x 150mm x 36mm

£616.93 ~~£690.38~~ -10%

Limited stock only available on quotation

Specifications

Width	36mm
Inner Diameter	85mm

Outer Diameter	150mm
Weight	2.60Kg

Bore diameter	d	85	mm
Width	B	36	mm
Shoulder/recess diameter outer ring	D₁	≈133
Chamfer dimension outer ring	r_1,2	min.2

Outside diameter	d₂	150	mm
Shoulder diameter inner ring	d₁	≈103
Permissible axial displacement from the normal position of one bearing ring relative to the other on bearings with a cage or in full complement bearings when displaying away from the retaining ring	s₁	max.7.1
