| Series | excelon | ||
| adjusting screw | steel | ||
| body | aluminium | ||
| bowl | polycarbonate | ||
| drain type | manual | ||
| filter element | sintered polypropylene | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 145 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 50 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 10 bar | ||
| Port size | g1/4 | ||
| range | b73g | ||
| replaced flag | yes |
| adjusting knob | acetal resin | ||
| Adjustment | knob | ||
| bonnet | aluminium | ||
| bowl type | polymer with guard | ||
| elastomers | neoprene | ||
| filter element m particlesize micron | 40 μm | ||
| gauge port | rc1/8 | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 122 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 145 psi | ||
| partially replaced part | b82g-2gk-qp3-rmg|b82g-2gk-qp3-rmn | ||
| product style | modular | ||
| relievingnonrelieving | relieving | ||
| retrieve price | true |
