| Minimum chamfer dimension | rmin | 0.30 | mm |
| Contact angle | α | 15 | ° |
| Bore diameter | d | 20 | mm |
| Width | B | 9 | mm |
| Basic static load rating, radial | C0r | 3,200 | |
| Limiting speed for grease lubrication | nG Grease | 43,000 |
| Outside diameter | D | 37 | mm |
| Basic dynamic load rating, radial | Cr | 7,400 | |
| Fatigue load limit, radial | Cur | 340 | N |
| Diameter shaft shoulder | da | 24 | mm |
| Shoulder diameter outer ring | Da | 33.50 | mm |
| Maximum recess radius | ra max | 0.15 | mm |
| Diameter shaft shoulder clearance | da | h12 | |
| Shoulder diameter outer ring clearance | Da | H12 | |
| Distance between the apexes of the pressure cones | a | 8.30 | mm |
