| Note on materials | RoHS-compliant | ||
| Material shock absorber insert | Bronze | ||
| Product weight | 1,7 g | ||
| Sound pressure level | 71 dB(A) | ||
| Note on operating and pilot medium | Lubricated operation possible | ||
| Flow rate to atmosphere | 260 l/min | ||
| Symbol | 00991473 | ||
| Mounting position | optional |
| Material screw-in stud | Brass | ||
| Pneumatic connection | 10-32 UNF-2A | ||
| Ambient temperature | -40 °C ... 80 °C | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Operating pressure | 0 bar ... 10 bar | ||
| Size of pack | 20 |
