| Pneumatic connection | M5 | ||
| Product weight | 72 g | ||
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 121 N | ||
| Ambient temperature | -20 °C ... 80 °C | ||
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Operating pressure | 1 bar ... 10 bar | ||
| Position detection | Without | ||
| Mode of operation | Double-acting | ||
| Cushioning | Elastic cushioning rings/plates at both ends | ||
| Stroke | 25 mm | ||
| Material housing | Wrought aluminium alloy Anodised | ||
| Material cover | Wrought aluminium alloy Anodised |
| Type of mounting | With through-hole With accessories Either: | ||
| Moving mass | 19 g | ||
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 90 N | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Symbol | 00991227 | ||
| Design | Piston Piston rod | ||
| Mounting position | optional | ||
| Piston diameter | 16 mm | ||
| Material piston rod | High-alloy steel | ||
| Material seals | NBR TPE-U(PU) |
